Belt-driven Centrifugal Blower rau Cua thiab Gas Tes

Kev kub ceev centrifugal blower IE3 / IE4 high efficiency lub cev muaj zog (Siemens / ABB)
Lub zog 5.5kw-7.5kw Cua ntws: 1200-3400m³/h Siab: 180-290mbar
Super airflow thiab txuag hluav taws xob

Xa kev nug

Muaj nuj nqi

Nyob rau hauv txoj kev loj hlob ntawm HANK txoj siv-hom high-speed centrifugal blower, peb cov engineers txuas ntxiv txhim kho qhov kev ua tau zoo thiab thev naus laus zis, tshwj xeeb, lub suab nrov thiab ruaj khov ntawm cov khoom siv thaum lub sijhawm ua haujlwm tas li sim, thiab tsuas yog tam sim no cov neeg siv khoom ntawm HANK blower kom qhuav lub tshuab nqus tsev. kev lees paub.

Hank's high-speed centrifugal blower tuaj yeem siv ua ke nrog aluminium alloy lossis stainless hlau cua riam kom qhuav 95% -100% ntawm cov kua rau saum npoo ntawm cov khoom.

201

Technical Parameter

Qauv	Lub cev muaj zog	Hwj chim	Qhov hluav taws xob	Max airflow	Ntau zaus	Siab	Lub tshuab nqus tsev	inlet & tawm	Qhov hnyav
Qauv	Lub cev muaj zog	(KW)	(V)	(m³/h)	(Hz)	(mbar)	(mbar)	(mm)	KG
HANK70-5.5	IEC/NEMA	5.5 hli (7.5HP)	380	1200	50	240	-220	102 hli & 76mm	91
HANK70-7.5	IEC/NEMA	7.5 hli (10 HP)	380	1470	50	260	-225	102 hli & 102 hli	101
HANK-85-7.5	IEC/NEMA	7.5 hli (10 HP)	380	1700	50	180	-170	102 hli & 102 hli	103
HANK100-11	IEC/NEMA	11 (15HP) Hwj chim	380	1700	50	240	-220	102 hli & 102 hli	140
HANK150-15	IEC/NEMA	15 (20HP) Hwj chim	380	2100	50	240	-230	102 hli & 102 hli	156
HANK150-18.5	IEC/NEMA	18.5 TSI (25HP)	380	2125	50	290	-270	102 hli & 102 hli	185
HANK200-22	IEC/NEMA	22 (30HP) Hwj chim	380	3400	50	240	-225	102 hli & 102 hli	220

Ambient kub-12 degree -40 degree

Ib lub twj tso kua mis

Muab ob npaug rau twj

HANK centrifugal blower nta

* ABB lub cev muaj zog, IP55 qib tiv thaiv, rwb thaiv tsev chav H

* Cov khoom tseem ceeb tau txais lub zog siab ntawm ADC12 aluminium alloy tuag-casting

* Tau raws lub axial bearing installation, ntau yam kev ua tau zoo.

* Siv lub MAZAKCNC machining center, SCHENCK ntsuas tshuab, Zeiss peb-dimensional soj ntsuam cov khoom.

HANK-70 5.5KW & HANK-70 7.5KW daim duab kos duab

116

117

HANK-70 5.5KW & HANK-70 7.5KW kev ua haujlwm nkhaus

118

* Thov paub meej tias qhov kawg installation demension nrog peb vim cov khoom hloov tshiab *

Thaum siv peb lub tshuab blower, pls ua tib zoo xyuas qhov chaw teeb tsa thiab ua cov kav dej tsim nyog thiab xaim. rau koj yooj yim, Hank siab ceev centrifugal blower muab hloov tau cua qhov hluav taws xob qhov chaw rau koj xaiv. Thov qhia qhov chaw qhov hluav taws xob thaum xaj, hauv qab Hank kos duab rau siv.

Hais txog HANK blower hauv kev lag luam steel

Txawm hais tias cov hlau yog tshiab los ntawm lub cub tawg, nyob rau hauv cov theem kawg ntawm kev tu, polishing, stamping los yog painting, Airhank lub high-speed centrifugal blower thiab high-efficiency cua riam tshuab yuav siv tau zoo nyob rau hauv txhua txoj kev tsim. Nrog rau kev ua kom nrawm nrawm hauv cov chaw tsim khoom, cov txheeb ze nce hauv lub zog hluav taws xob, roj thiab cov dej ntub dej, thiab cov xim tswj cov tshuab, koj yuav tsis tas siv Airhank cov cuab yeej ua haujlwm siab cua tshuab. Nrog rau Airhank High Efficiency Air Riam System, koj yuav tsis xav tau squeegee chais, cov cua compressed ntau, lub tshuab cua loj lossis cov khoom siv cua sov, txo cov nqi tsim khoom thiab siv tau ntau heev.

202

HANK kev kub ceev centrifugal blower export ntim

112003

FAQ

Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?

A: Peb yog cov chaw tsim khoom tshwj xeeb hauv sab channel blower, kev kub ceev centrifugal blower thiab cua riam ziab tshuab. Lub tuam txhab yeej ib txwm hais rau kev koom ua ke ntawm kev txhim kho, pwm tsim, tuag-casting, precision machining, sib dhos thiab automated xim txau.

Q: Koj puas tuaj yeem muab cov ntaub ntawv hais txog koj cov ntawv pov thawj?

A: Peb cov ntawv pov thawj suav nrog CE, RoHs, thiab ISO9001.

Q: Hom kev them nyiaj twg koj txais?

A: Peb lees txais T / T, Western Union, PayPal, kom ntseeg tau yooj yim rau peb cov neeg siv khoom.

Q: Koj puas tuaj yeem ua OEM thiab ODM?

A: Yog, OEM thiab ODM yog ob qho tib si txais.
